What is a WAF?

#

The term WAF stands for Web Application Firewall.

A traditional firewall mainly operates at the network layer, filtering packets based on source IP, destination IP, source port, destination port, and protocol (TCP/UDP/ICMP). In other words, it ensures that only authorized connections reach the server, but it does not understand the content of the traffic.

The WAF, however, goes further: it is specifically designed to protect web applications. Instead of only analyzing addresses and ports, the WAF inspects the content of HTTP/HTTPS requests. This allows it to identify and block malicious access attempts that a traditional firewall would miss.

Examples of threats a WAF helps mitigate

#

• SQL Injection – when malicious SQL commands are sent to manipulate databases.
• Cross-Site Scripting (XSS) – injection of scripts that can steal user data.
• Malicious bots – attempting to exploit vulnerabilities or overload the application.
• Brute force – automated attempts to guess usernames and passwords.

In summary

#

• Traditional firewall = focuses on network → controls who can connect (based on IP, ports, and protocols).
• WAF = focuses on web applications → analyzes what’s inside the request and protects against attacks targeting site functionality.

In other words, the WAF acts as a shield between the internet and your web application, blocking threats before they can cause damage.

What is CrowdSec?

#

CrowdSec is the WAF we use here at Gole.
It is an open-source, collaborative, and modern solution that not only protects your application in real time but also learns from attacks occurring elsewhere in the world.

That means: when a malicious IP is detected in one environment, the entire CrowdSec community can benefit and block that same IP.

How does CrowdSec work?

#

The process is simple to understand:

1. Monitors logs from services such as Nginx, Traefik, SSH, web applications.
2. Detects suspicious behavior (brute force, scans, abuses).
3. Automatically blocks malicious IPs.
4. Shares this information anonymously, strengthening the protection network.

Key Features

#

• Real-time monitoring: captures logs from services like Nginx, Traefik, SSH, and more.
• Attack and abuse detection: identifies brute force, scans, and anomalous behavior.
• Automatic IP blocking: applies local or remote sanctions, protecting your applications.

Step by Step: Configuring CrowdSec in Kubernetes

#

1. Add the Helm repository and get default values**

#

helm repo add crowdsec https://crowdsecurity.github.io/helm-charts
helm repo update
helm show values crowdsec/crowdsec > crowdsec-default-values.yaml

2. Edit the crowdsec-default-values.yaml file

#

a) Configure log acquisition (Traefik)

#

agent:
  acquisition:
    - namespace: traefik
      podName: traefik-*
      program: traefik

b) Instance registration (LAPI)

#

lapi:
  env:
    - name: ENROLL_KEY
      value: "YOUR_ENROLL_KEY"
    - name: ENROLL_INSTANCE_NAME
      value: "my-k8s-cluster"
    - name: ENROLL_TAGS
      value: "k8s linux production"

c) Persistent volumes

#

persistentVolume:
  data:
    enabled: true
    storageClassName: "your-storage-class-name"
    size: 1Gi

  config:
    enabled: true
    storageClassName: "your-storage-class-name"
    size: 100Mi

3. Create namespace

#

kubectl create ns crowdsec

4. Install CrowdSec

#

helm install crowdsec crowdsec/crowdsec -n crowdsec -f crowdsec-default-values.yaml

5. Configure bouncers (Traefik and Nginx)

#

a) Create API Key

#

kubectl -n crowdsec exec -it crowdsec-lapi-* -- sh
cscli bouncers add traefik

b) Configure middleware in Traefik

#

apiVersion: traefik.io/v1alpha1
kind: Middleware
metadata:
  name: bouncer
  namespace: traefik
spec:
  plugin:
    bouncer:
      CrowdsecLapiKey: <YOUR_API_KEY>
      crowdsecLapiHost: "crowdsec-service.crowdsec.svc.cluster.local"
      crowdsecLapiPort: "8080"
      crowdsecAppsecHost: "crowdsec-appsec-service.crowdsec.svc.cluster.local"
      crowdsecAppsecPort: "7422"
      crowdsecAppsecScheme: http
      Enabled: true
      logLevel: DEBUG
      crowdsecMode: appsec

c) Configure bouncer in Nginx

#

controller:
  extraInitContainers:
  - name: init-clone-crowdsec-bouncer
    image: crowdsecurity/lua-bouncer-plugin
    env:
      - name: API_URL
        value: "http://crowdsec-service.crowdsec.svc.cluster.local:8080"
      - name: API_KEY
        value: "<API KEY>"
      - name: BOUNCER_CONFIG
        value: "/crowdsec/crowdsec-bouncer.conf"

6. Enable AppSec (WAF)

#

appsec:
  enabled: true
  acquisitions:
    - source: appsec
      listen_addr: "0.0.0.0:7422"
      path: /
      appsec_config: crowdsecurity/crs-vpatch
      labels:
        type: appsec
  env:
    - name: COLLECTIONS
      value: "crowdsecurity/appsec-wordpress"

Advanced Monitoring with Grafana

#

The CrowdSec console has a limit of 500 alerts, which can restrict the visibility of events in high-traffic environments. For a complete and detailed monitoring, we created a Grafana dashboard that allows you to observe IP blocks, attacks, and security decisions in real-time.

This dashboard includes:

• Block Total for Pods: Number of blocked attempts per pod, helping to identify which pods are under the most attacks.
• Attacks by Scenarios: Distribution of attacks based on CrowdSec detection scenarios, showing the most frequent threat types.
• Total Ban by IP: List of blocked IPs, the scenario, and total occurrences, allowing easy tracking of malicious sources.
• Decisions Log: Detailed decision logs with timestamps and request data, providing full transparency of CrowdSec actions.

Access the dashboard: CrowdSec Monitoring on Grafana

This feature is essential for security teams to monitor, analyze, and respond quickly to threats in the infrastructure.

Conclusion

#

With these configurations, CrowdSec is integrated into your Kubernetes cluster, monitoring logs, registering instances, and protecting your applications with Traefik, Nginx, and WAF AppSec.

Access the console: https://app.crowdsec.net/security-engines
